Description
Synology RackStation RS3621xs+
Safeguard your business assets
Synology RackStation RS3621xs+ is a powerful 12-bay storage server. Its 6-core processor enables compute-intensive services while its redundant power, ECC memory, and Btrfs file system safeguard mission-critical data. Capable of delivering 189,098 4K random read IOPS and 4,718 MB/s sequential read throughput1, it is ideal for small businesses.
Synology RackStation RS3621xs+ SPECIFICATIONS
Reliability first
Service continuity is at the core of the Synology RackStation RS3621xs+ design.
Redundant power
Dual PSUs provide protection against a PSU failure or accidental cord removal while hot-swappable fans can be replaced without powering down the system.
Near-zero downtime
Synology High Availability (SHA) pairs two identical units together creating an active-passive cluster with minute-level failover
Next-generation file system
Btrfs prevents data corruption and reduces maintenance overheads with advanced storage technologies and optimized snapshots
Synology RackStation RS3621xs+
- 1Power button and indicator
- 2Alert Off Button
- 3Drive tray
- 4Drive status indicator
- 5Power Port
- 6PSU Indicators & Alert Off Buttons
- 7PSU fan
- 8Console port
- 91GbE RJ-45 port
- 10USB 3.2 Ports
- 11Expansion port
- 12PCIe expansion slot
- 13Reset button
Synology RackStation RS3621xs+
CPU |
CPU Model | Intel Xeon D-1531 |
|---|---|---|
| CPU Architecture | 64-bit | |
| CPU Frequency | 6-core 2.2 (base) / 2.7 (turbo) GHz | |
| Hardware Encryption Engine (AES-NI) | ||
Memory |
System Memory | 8 GB DDR4 ECC UDIMM |
| Memory Module Pre-installed | 8 GB (8 GB x 1) | |
| Total Memory Slots | 4 | |
| Maximum Memory Capacity | 64 GB (16 GB x 4) | |
| Notes |
|
|
Storage |
Drive Bays | 12 |
| Maximum Drive Bays with Expansion Unit | 36 (RX1217/RX1217RP x 2) | |
| Compatible Drive Type* |
|
|
| Maximum Single Volume Size* |
|
|
| Hot Swappable Drive | ||
| Notes |
|
|
External Ports |
RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| USB 3.2 Gen 1 Port* | 2 | |
| Expansion Port | 2 | |
| Notes | The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019. | |
PCIe |
PCIe Expansion | 2 x Gen3 x8 slots (x8 link) |
File System |
Internal Drives |
|
| External Drives |
|
|
| Notes | exFAT Access is purchased separately in Package Center. | |
Appearance |
Form Factor (RU) | 2U |
| Size (Height x Width x Depth) | 88 mm x 482 mm x 724 mm | |
| Weight | 14.5 kg | |
| Rack Installation Support* | 4-post 19″ rack (Synology Rail Kit – RKS1317) | |
| Notes | The rail kit is sold separately | |
Others |
System Fan | 80 mm x 80 mm x 4 pcs |
| Synology RackStation RS3621xs+ | Fan Speed Mode |
|
| Easy Replacement System Fan | ||
| Power Recovery | ||
| Noise Level* | 50.2 dB(A) | |
| Scheduled Power On / Off | ||
| Wake on LAN / WAN | ||
| Power Supply Unit / Adapter | 500 W | |
| Redundant Power Supply | ||
| AC Input Power Voltage | 100 V to 240 V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption* | 140.01 W (Access) 65.94 W (HDD Hibernation) |
|
| British Thermal Unit | 477.43 BTU/hr (Access) 224.86 BTU/hr (HDD Hibernation) |
|
| Synology RackStation RS3621xs+ | Notes |
|
Temperature |
Operating Temperature | 0°C to 35°C (32°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
Certification |
|
|
Warranty |
5 Years | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt | |
Environment |
RoHS Compliant | |
Packaging Content |
|
|
Optional Accessories |
|
|
