Description
Synology Unified Controller UC3200
Reliable, high availability SAN
Two independent controllers in the Synology Unified Controller UC3200 SAN work simultaneously to ensure interruption-free iSCSI and FC services.
Easily scalable
High-performance SAS drives slots and support for up to 576 TB, fully expanded, ensures the Synology Unified Controller UC3200 is ready for any project. For mission-critical and sensitive data, native support for SEDs provides hardware-level encryption for all data.
Performance
Works with mainstream virtualization systems
Optimized for virtualization environments.
- Integrated with VMware vSphere® 6.5, Microsoft Hyper-V®, and VAAI to offload storage operations and optimize computational efficiency.
- Windows Offloaded Data Transfer (ODX) is supported to speed up data transfer and migration rates.
- Turn Synology Unified Controller UC3200 into a block-based storage component with the support of OpenStack® Cinder.
- Compliance with the ALUA industry standard allows hosts to identify optimized paths to increase data transfer performance and efficiency.
Learn more about Storage for Virtualization
Engineered for iSCSI/FC SAN
DSM UC, an operating system designed to ease the learning curve, allows you to manage the two controllers from one single portal. The built-in monitor applications display the status at a glance and send prompt notifications when important events occur so that IT administrators can stay alert to potential problems and respond in the shortest time possible.
A unified interface for intuitive management
Cutting-edge LUN features
Advanced LUN functionality significantly improves VM performance and offers lightning-fast snapshot creation, recovery, and cloning, as well as VMware VAAI and Windows ODX support.
Intuitive management
A streamlined management interface makes connection and permission management exceptionally easy, even in large-scale SAN environments.
For large and small deployments
Support for iSCSI, as well as Fibre Channel, means that Synology storage systems integrate as easily in smaller setups as in enterprise environments.
Disaster-proof your critical data
Leverage application-aware snapshot protection and instant recovery of virtual machines on LUNs in case of disaster. Snapshot Replication (enabled by the Btrfs file system) offers schedulable and near-instantaneous data protection, while UC3200 supports up to 4,096 system-wide snapshots of local volumes or off-site servers.
5-year warranty
At Synology, we are committed to product innovation and quality. Synology guarantees a robust and reliable data management experience with a 5-year limited warranty, providing responsive technical support and hardware replacement services to maximize your return on investment.
More resources
Administrator’s Guide
This guide will walk you through the process of the initial setup and optimal deployment of UC3200.
Tutorials & FAQ
We offer a variety of tutorial and troubleshooting articles for Synology Unified Controller UC3200 on our tutorials & FAQ page.
Contact Us
Reach out to us whenever you have questions regarding Synology UC3200. Our experts will resolve your problems in no time.
Synology Unified Controller UC3200
- 1
Power button and indicator - 2
Beep off button - 3
Drive tray - 4
Drive status indicator
- 5
Power port
- 6
PSU indicator and beep off button - 7
PSU fan - 8
PCIe expansion slot - 9
Console port - 10
1GbE RJ-45 port
- 11
10GbE RJ-45 (10GBASE-T) port - 12
Expansion port - 13
Reset button - 14
Power Indicator - 15
Status Indicator
- 16
Alert Indicator - 17
Remove Indicator
|
Hardware Specifications
|
||
|---|---|---|
|
Controller
|
||
|
Controller
|
Number of Controller Module | 2 |
|
CPU
|
||
|
CPU
|
CPU Model | Intel Xeon D-1521 |
| CPU Quantity | 1 (per controller) | |
| CPU Architecture | 64-bit | |
| CPU Frequency | 4-core 2.4 (base) / 2.7 (turbo) GHz | |
| Hardware Encryption Engine (AES-NI) | ||
|
Memory
|
||
|
Memory
|
System Memory | 8 GB DDR4 ECC UDIMM (per controller) |
| Memory Module Pre-installed | 8 GB (8 GB x 1) (per controller) | |
| Total Memory Slots | 4 (per controller) | |
| Maximum Memory Capacity | 64 GB (16 GB x 4) (per controller) | |
| Notes |
|
|
|
Storage
|
||
|
Storage
|
Drive Bays | 12 |
| Maximum Drive Bays with Expansion Unit | 36 (RXD1219sas x 2) | |
| Compatible Drive Type* (See all supported drives) |
|
|
| Maximum Single Volume Size* | 108 TB | |
| Hot Swappable Drive* | ||
| Notes |
|
|
|
External Ports
|
||
|
External Ports
|
RJ-45 1GbE LAN Port | 2 (with Link Aggregation / Failover support) (per controller) |
| RJ-45 10GbE LAN Port | 1 (per controller) | |
|
PCIe
|
||
|
PCIe
|
PCIe Expansion | 1 x Gen3 x8 slot (x8 link) (per controller) |
| Add-In-Card Support |
|
|
|
File System
|
||
|
File System
|
Internal Drives | Btrfs |
|
Appearance
|
||
|
Appearance
|
Size (Height x Width x Depth) | 88 mm x 430.5 mm x 692 mm |
| Size (Height x Width x Depth) (with server ears) | 88 mm x 482 mm x 724 mm | |
| Weight | 19.7 kg | |
| Rack Installation Support* | 4-post 19″ rack (Synology Rail Kit – RKS-02) | |
| Notes | The rail kit is sold separately | |
|
Others
|
||
|
Others
|
System Fan | 60 mm x 60 mm x 2 (per controller) |
| Fan Speed Mode |
|
|
| Easy Replacement System Fan | ||
| Power Recovery | ||
| Noise Level* | 51.3 dB(A) | |
| Power Supply Unit / Adapter | 500W | |
| Redundant Power Supply | ||
| AC Input Power Voltage | 100 V to 240 V AC | |
| Power Frequency | 50/60Hz, Single Phase | |
| Power Consumption | 417.48 W (Access) | |
| British Thermal Unit | 1425.45 BTU/hr (Access) | |
| Notes |
|
|
|
Temperature
|
||
|
Temperature
|
Operating Temperature | 0°C to 35°C (32°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
|
Certification
|
||
|
Certification
|
|
|
|
Warranty
|
||
|
Warranty
|
5 Years | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) | |
|
Environment
|
||
|
Environment
|
RoHS Compliant | |
|
Packaging Content
|
||
|
Packaging Content
|
|
|
|
Optional Accessories
|
||
|
Optional Accessories
|
|
|
| Notes | All memory modules will operate at the maximum frequency specified by the CPU manufacturer. | |
|
DSM UC Specifications
|
||
|---|---|---|
|
Storage Management
|
||
|
Storage Management
|
Maximum Internal Volume Number | 32 |
| Maximum iSCSI Target Number | 128 | |
| Maximum LUN | 128 | |
| Advanced LUN (Clone/Snapshot) Support | ||
| Maximum Number of Snapshots per Advanced LUN | 256 | |
| SSD Read / Write Cache (White Paper) | ||
| SSD TRIM | ||
| RAID Group | ||
| Supported RAID Type |
|
|
| RAID Migration |
|
|
| Volume Expansion with Larger HDDs |
|
|
| Volume Expansion by Adding a HDD |
|
|
| Global Hot Spare Supported RAID Type |
|
|
|
Account & Shared Folder
|
||
|
Account & Shared Folder
|
Maximum Local User Accounts | 65 |
|
Virtualization
|
||
|
Virtualization
|
VMware vSphere with VAAI | |
| Windows Server 2016 | ||
| Windows Server 2019 | ||
| Citrix Ready | ||
| OpenStack | ||
|
Snapshot Replication
|
||
|
Snapshot Replication
|
Maximum Number of Replication | 32 |
| Maximum of System Snapshots | 4,096 | |
|
General Specifications
|
||
|
General Specifications
|
Networking Protocols |
|
| Supported Clients |
|
|
| Supported Language | English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文 | |
Notes:
- Model specifications are subject to change without prior notice.
- The figures are based on Synology internal testing. Each performance test is done individually. No other services or applications are processed at the same time.
- The actual performance may be lower than lab testing figure due to differences in server configuration, deployment, and the number of active operations.
- If usage requirements exceed the specifications above, please contact our regional partners for professional advice.
