Description
Synology SNV3500 M.2 2210 NVME SSD
Enterprise NVMe solid-state drives
M.2 2280
SNV3400 Series, tailored for Synology NAS with built-in M.2 slots.
M.2 22110
SNV3500 Series, engineered for more demanding environments.
Supercharge your NAS/SAN
Synology SNV3500 M.2 2210 NVME SSD is designed to intelligently work with Synology DiskStation Manager (DSM) to boost I/O performance. These high-performance NVMe drives accelerate the slower but higher-capacity storage space provided by traditional hard drives, enabling cost-effective, in-place upgrades for existing systems.
Performance
Up to 70,000 4K random write IOPS1
Endurance
Up to 1,022 TBW2
Analytics
Actionable insight for optimal performance and longevity3
Updates
Automatic firmware updates with DSM4
Consistently fast caching for 24/7 environments
Designed specifically for Synology systems, the SNV3400/3500 Series SSDs are built for maximum performance consistency. Each drive is rated for up to 400,000/70,000 4K random read/write IOPS1 across the usable lifespan of the drive. Endurance of up to 1,022 TBW ensures longevity.2
Data integrity safeguards
Full end-to-end data protection and power loss protection (SNV3500 Series only)5 ensure data integrity and help prevent corruption issues during unexpected shutdown events.
Better analytics
Synology drives can provide more accurate insights about drive health in Synology DSM, including the workload placed on them over time.
Timely notifications
Timely notifications of potential issues help you plan ahead to attain consistent system performance and longevity.
Optimal use
Easy monitoring allows you to make optimal use of each SSD.
Effortless firmware updates
Synology DSM keeps your drives up to date automatically. No need for separate maintenance sessions.4
Purpose-built for Synology NAS
Synology SNV3400/3500 Series drives are thoroughly validated for use in our systems following each engineering change. Each firmware and component is strictly controlled. Intensive I/O stress, power cycling, and temperature stress tests ensure that all products meet our strictest standards for quality and reliability.
| Hardware Specifications | SNV3410-400G | SNV3510-400G | SNV3510-800G | |
|---|---|---|---|---|
| General | Capacity | 400 GB | 400 GB | 800 GB |
| Form Factor | M.2 2280 | M.2 22110 | M.2 22110 | |
| Interface | NVMe PCIe 3.0 x4 | NVMe PCIe 3.0 x4 | NVMe PCIe 3.0 x4 | |
| Performance | Sustained Sequential read (128 KB, QD32) | 3,000 MB/s | 3,000 MB/s | 3,100 MB/s |
| Sustained Sequential write (128 KB, QD32) | 750 MB/s | 750 MB/s | 1,000 MB/s | |
| Sustained Random Read (4KB, QD256) | 225,000 IOPS | 225,000 IOPS | 400,000 IOPS | |
| Sustained Random Write (4KB, QD256) | 45,000 IOPS | 45,000 IOPS | 70,000 IOPS | |
| Notes | All performance measurement were reached in full sustained mode based on the JESD219A enterprise workload, defined by JEDEC Solid State Technology Association. | |||
| Endurance and Reliability | Terabytes Written (TBW)* | 491 TB | 491 TB | 1,022 TB |
| Mean Time Between Failures (MTBF) | 1.8 million hours | 1.8 million hours | 1.8 million hours | |
| Uncorrectable Bit Error Rate (UBER) | < 1 sector per 1017 bits read | < 1 sector per 1017 bits read | < 1 sector per 1017 bits read | |
| Power Loss Protection | – | |||
| Warranty* | 5 Years | 5 Years | 5 Years | |
| Notes |
|
|||
| Power Consumption | Supply Voltage | 3.3V (± 5%) | 3.3V (± 5%) | 3.3V (± 5%) |
| Active Read (Typ.) | 3.5 W | 4.0 W | 6.2 W | |
| Active Write (Typ.) | 3.3 W | 3.6 W | 5.1 W | |
| Idle | 1.6 W | 1.6 W | 1.7 W | |
| Notes | Power consumption may differ according to configurations and platforms. | |||
| Temperature | Operating Temperature | 0°C to 70°C (32°F to 158°F) | 0°C to 70°C (32°F to 158°F) | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) | -40°C to 85°C (-40°F to 185°F) | -40°C to 85°C (-40°F to 185°F) | |
| Others | Size (Height x Width x Depth) | 3.5 mm x 22 mm x 80 mm | 4.5 mm x 22 mm x 110 mm | 4.5 mm x 22 mm x 110 mm |
| Certification |
|
|
|
|
| Compatibility | ||||
