DS3622xs+

DS3622xs+

Synology Diskstation 3622xs+ Intel Xeon D-1531 16GB Desktop 12 bays

Categories: 12bay diskless DS& RS, Synology

Add to wishlist

Description
Reviews (0)
Q & A

Description

DS3622xs+

Specifications
CPU	CPU Model	Intel Xeon D-1531
	CPU Quantity	1
	CPU Core	6
	CPU Architecture	64-bit
	CPU Frequency	2.2 (base) / 2.7 (turbo) GHz
	Hardware Encryption Engine
Memory	System Memory	16 GB DDR4 ECC SODIMM
	Memory Module Pre-installed	16 GB (8 GB x 2)
	Total Memory Slots	4
	Maximum Memory Capacity	48 GB (8 GB x 2 + 16 GB x 2)
	Notes	Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion. For multi-module memory configurations, all modules must be identical and share the same model number.
Storage	Drive Bays	12
	Maximum Drive Bays with Expansion Unit	36 (DX1222 x 2)
	Drive Type	3.5″ SATA HDD 2.5″ SATA HDD 2.5″ SATA SSD
	Hot Swappable Drive*
	Notes	Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability.
External Ports	RJ-45 1GbE LAN Port	2
	RJ-45 10GbE LAN Port	2
	Out-of-Band Management LAN Port	1
	USB 3.2 Gen 1 Port	2
	Expansion Port	2
	Expansion Port Type	Mini-SAS HD
	Notes	This device’s 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
PCIe	PCIe Expansion	1 x Gen3 x8 slot (x8 link)
Appearance	Size (Height x Width x Depth)	270 mm x 300 mm x 340 mm
	Weight	9.8 kg
Others	System Fan	120 mm x 120 mm x 2 pcs
	Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
	Easy Replacement System Fan
	Power Recovery
	Noise Level*	25 dB(A)
	Scheduled Power On / Off
	Wake on LAN / WAN
	Power Supply Unit / Adapter	550 watts
	AC Input Power Voltage	100V to 240V AC
	Power Frequency	50/60 Hz, Single Phase
	Power Consumption*	94.42 watts (Access) 54.33 watts (HDD Hibernation)
	British Thermal Unit	322.39 BTU/hr (Access) 185.51 BTU/hr (HDD Hibernation)
	Notes	Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s). Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature	Operating Temperature	0°C to 40°C (32°F to 104°F)
	Storage Temperature	-20°C to 60°C (-5°F to 140°F)
	Operating Humidity	8% to 80% RH
	Storage Humidity	5% to 95% RH
Certification	FCC CE BSMI VCCI RCM UKCA EAC KC BIS UL
Warranty	5 Years
	Notes	The warranty period starts from the purchase date as stated on your purchase receipt.
Environment	RoHS Compliant
Packaging Content	Main Unit X 1 Accessory Pack X 1 AC Power Cord X 1 RJ-45 LAN Cable X 2 Quick Installation Guide X 1
Optional Accessories	DDR4 ECC SODIMM: D4ES02-8G/D4ES01-16G Expansion Units: DX1222 Enterprise Series 3.5″ SATA HDD:HAT5300 Series Plus Series 3.5″ SATA HDD: HAT3300 Series Enterprise Series 2.5″ SATA SSD: SAT5200 Series M.2 SSD & 10GbE Combo Adapter Card: E10M20-T1 M.2 SSD Adapter Card: M2D20 25GbE Network Interface Card: E25G30-F2 10GbE Network Interface Card: E10G30-F2/E10G30-T2/E10G18-T1
